BALL VALVES
BOLTED SIDE PIECE CAST CARBON , STAINLESS OR ALLOY STEELSIZE:- 2″ -12″, ASME CLASS:- 150# – 600#
DESIGN FEATURES
- 2 & 3-Piece, Side Entry / Split Body, Fire Safe, Anti-static & Blow-out Proof Stem, Floating & Trunnion type Ball design
- Ball:- Full bore or reduced bore.
- End Connection:- A choice of Flat flanged, RF flanged, RTJ & Butt Welding end fas per piping flexibility.
- Operation:- Lever upto 6″ Size & Gear for above size
- Packing:- Std packing multiple V-teflon packing. combined with live loading, maintains packing compression under high-cycle and severe service applications. Graphite packing is used for high-temperature situation.
